Oojo Aluminium Aluminium

Name: Window Aleminim ati ilẹkun 4
Uploaded: 2023-09-14T01:14:59+08:00
Description: Awọn ilẹkun aluminiomu ti ọja ni orisirisi awọn imọ-ẹrọ itọju dada, ọpọlọpọ awọn irugbin igi

$93-210 /Square Meter

Iru owo sisan:	T/T
Incoterm:	FOB,CFR,CIF,EXW
Min. Bere fun:	500 Square Meter
Iṣowo:	Ocean,Land,Express
Port:	SHENZHEN,GUANGZHOU ,FOSHAN

Frame material:

Aluminum Alloy

Kan si Nisisiyi

Ọja Apejuwe

Awọn eroja Ọja

Apoti & Ifijiṣẹ

Ọja Apejuwe

Awọn eroja Ọja

Aṣeṣe No.: SD01

Brand: Guang yuan

After-sales Service: Online Technical Support, Onsite Inspection, Other

Engineering Solution Capability: Graphic Design, Total Solution For Projects

Application Scenario: Hotel, Villa, Apartment, Office Building, Hospital, School, Mall, Courtyard, Supermarket, Warehouse, Kitchen, Other, Outdoor, Exterior

Design Style: Modern, Traditional, Chinese

Place Of Origin: China

Apoti & Ifijiṣẹ

Ta sipo	:	Square Meter
Apeere Aworan	:

The file is encrypted. Please fill in the following information to continue accessing it

Window Aleminim ati ilẹkun 4

Window Aleminim ati ilẹkun 5



Ọja Apejuwe

Awọn ilẹkun aluminiomu ti ọja ni orisirisi awọn imọ-ẹrọ itọju dada, ọpọlọpọ awọn irugbin igi ati awọn awọ lati yan lati, le pade ọpọlọpọ awọn ohun elo ọṣọ ti ayaworan. Awọn olutọju Luminomu kan ti olupese Olupese jẹ ki o jẹ aṣa apẹrẹ apẹrẹ igbalode jẹ ara pam, ati awọn profaili ti o tayọ ati awọn profaili aluminiomu ṣẹda itọwo pupọ.

# 100/150 Desen Shall Dengrade ilẹkun jẹ rọrun ni apẹrẹ, dan ninu ohun ti o daju, oninurere, ati iyebiye ninu iseda. Apẹrẹ Ọja jẹ Avant-garde, enclectic, fifihan eniyan ati njagun ti o ja. Aworan aworan ati ibaramu ibaraẹnisọrọ kọọkan miiran, eyiti kii ṣe mu itunu ati igbadun diẹ sii wa, ṣugbọn o tun jẹ ki iṣẹ ọna ọnà. # 100/150 Demiphar jarisi jara ti ilẹkun atilẹyin nipasẹ iseda, dan ati ẹlẹwa. Awọn ẹya ẹrọ ifipamọ-didara to gaju jẹ ohun-ini pupọ. Awọn ilẹkun Polimin Aluminiomu ti iṣowo ni imọ alailori, eyiti o wa ni ila pẹlu ẹda eniyan ti sunmọ iseda. Ile-aye ile ti ile gbona tan imọlẹ ifesi ati idiwọ igbeyo.

# 100/150 Demiphar jara sisun okun gba profaili tootọ, sisanra ti awọn profaili àmi jẹ 1.4mm, awọn orin mẹta le ni ipese pẹlu irin irin, irin alagbara, irin irin, ọpa aṣayan Lẹẹkọ, Ipese iṣẹ Lo ọkọ oju-irin kekere ti o ni eti idaduro omi fun iṣẹ mabomire, ati ewe ti ilẹkun ti ni ipese pẹlu ẹrọ egboogi-oju omi ati ẹrọ egboogi-Nan, eyiti o jẹ imọlẹ ko si ariwo nigba lilo gbigbe. Olutọju luminumu

Product Name	100/150 DEPIN Series Sliding Door
Manufacturing Standard	AS2047
Quality Certificate	ISO 9001:2015, ISO 14001:2015, CQM Certification, SGS
Aluminium Profiles	6063-T5 high quality thermal/non-thermal break aluminium profiles
Profiles Thickness	1.4mm for windows, 2.0mm for doors
Surface Treatment	Anodizing, electrophoresis, powder coating, fluorocarbon, and wooden color
Color	Silver, champagne, bronze, white, charcoal, black, brown, grey and wooden colors
Glazing Type	tempered glazing, tinted glazing, frosted glazing, reflective glazing, laminated glazing and LOW-E glazing
Glazing Thickness	Single tempered glazing: 5mm, 6mm, 8mm, 10mm and 12mm
	Double tempered glazing: 4+12A+4mm, 5+9A+5mm, 5+12A+5mm, 5+15A+5mm, 5+19A+5mm and 6+12A+6mm
Mesh	Stainless steel security mesh, diamond mesh, aluminium security mesh, and fiberglass flyscreen
	Retractable screen, fixed screen and sliding screen
Sealing	Chinese famous brand silicone and EPDM strips
Hardware	KINLONG, HOPPE, HOPO, SIEGENIA AUBI, CMECH
Architrave	Depending on the customer’s requirements
Guarantee	10 years to 20 years
Application	Residential houses, commercial buildings, luxurious villas, modular houses, prefab houses and steel structure houses
MOQ	1 set
Packing Details	EPE foam packing and wooden crate packing
Payment Term	1) T/T: 30% of total value as deposit by T/T within 3 days to confirm the order, and the balance to be paid by T/T before loading the container.
	2) L/C: 30% of total value as deposit to be paid by T/T within 3 days to confirm the order, and the balance to be paid by L/C at sight after loading the container.
	3) Big order: Pay 30% of total value as deposit by T/T within 3 day to confirm the order, and the balance to be paid by T/T after delivery against the copy of B/L.
STRUCTURAL PARAMETERS
Profile Thickness	Frame Depth					Sash Width
2.0mm	138mm					90mm
PERFORMANCE PARAMETERS
Heat Insulation(m2·K)	Sound Insulation(DB)		Water Tightness(PA)	Air Tightness		Wind Load(KPa)
4W	45DB		700PA	4.5≤92>3.0		3.5≤P3>4.0
Level 4	Level 4		Level 6	Level 8		Level 8
SHIPMENT
Standard Loading Quantity		1*20GP			1*40HQ
		Max. length: 5.85 meters			Max. length: 12 meters
		200 square meters			400 square meters
Standard Loading Port		HUANGPU / NANSHA / YANTIAN / SHEKOU
Shipping Methods		Ocean shipment, air shipment, land transportation and multi-transportation, etc.
